GP Batteries Lithium Coin=CR1616

RM 0.00






  • High energy density
  • Wide range of operating temperatures from -10°C to +60°C
  • Flat discharge voltage
  • Long shelf life of 10 years
  • Board range of sizes and models

Lithium Coin
GP Model Voltage (V) Dimension Nominal Capacity (mAh) Cross Reference
Dia
(mm)
Ht
(mm)
IEC JIS EVEREADY VARTA DURACELL
GPCR1/3N 3.0 11.6 10.8 160 CR1/3N CR1/3N - - DL1/3N
GPCR1025 3.0 10.0 2.5 30 CR1025 CR1025 ECR1025 CR1025 -
GPCR1216 3.0 12.5 1.6 25 CR1216 CR1216 ECR1216 CR1216 -
GPCR1220 3.0 12.5 2.0 36 CR1220 CR1220 ECR1220 CR1220 -
GPCR1616 3.0 16.0 1.6 55 CR1616 CR1616 ECR1616 CR1616 -
GPCR1620 3.0 16.0 2.0 78 CR1620 CR1620 ECR1620 CR1620 -
GPCR2016 3.0 20.0 1.6 90 CR2016 CR2016 ECR2016 CR2016 DL2016
GPCR2025 3.0 20.0 2.5 160 CR2025 CR2025 ECR2025 CR2025 DL2025
GPCR2032 3.0 20.0 3.2 220 CR2032 CR2032 ECR2032 CR2032 DL2032
GPCR2430 3.0 24.5 3.0 300 CR2430 CR2430 ECR2430 CR2430 DL2430
GPCR2450 3.0 24.5 5.0 610 CR2450 CR2450 ECR2450 CR2450 -
