Futaba S3001 Servo Standard with Ball Bearing

RM 0.00

This is a Standard Servo with a Ball Bearing on the output shaft. This has a "J" connector and uses a nylon gears.
This servo can produce high-current draw from your batteries. If using NiMH or LiPo batteries, make sure they are capable of delivering sufficient amps.

Single Top Ball Bearing
Same mounting as S148 and S9201 (individual rectangular grommets)
3-pole motor
One S3001 Standard Servo
One accessory package
Length: 1.6" (41mm)
Width: .8" (20mm)
Height: 1.4" (35mm)
Weight: 1.6 ounces (45.1g)
Torque: 44 oz-in at 4.8V 57 oz-in. at 6V
Transit: .23 sec./60° at 4.8V .19 sec./60° at 6V
